CYLINDER, SINGLE ACTING, SPRING RETURN, 10 TON, 10-1/8" STROKE

Features:

  • Aluminum bronze bearing reduces wear caused by aluminum bronze bearing reduces wear caused by off-center loads.
  • Maximum sized springs speed piston return and increase spring life.
  • Collar threads are standard on all c-series models, simplifying fixturing applications.
  • Removable rubber boots protect collar threads during transport and storage.
  • Solid steel cylinder body for durability.
  • Chrome plated piston rod resists wear and corrosion.
  • Wide range of accessories available that mount onto the piston rod, collar, or base.
  • Base mounting holes standard on 5 through 55 ton cylinders and optional on 75 and 100 ton cylinders.
  • A 3/8"NPTF female half coupler is standard.
  • Complies with ANSI/ASME B30.1 safety standards
Where to buy
Add to quote
  • Overview
  • Specifications
  • Documentation
RUGGED, HIGH QUALITY CYLINDER USED FOR LIFTING AND PRESSING.
Units:
  • Imperial
  • Metric
20.62
Specification
Imperial
Brand Power Team
Tonnage 100
Stroke 10.25
Return Type Spring-Return
Retracted Height 16.88 in
Cylinder Movement Single-Acting
Extended Height 27.13 in
Weight 51.26
Specification 12
Metric
Brand Power Team
Tonnage 90.72
Stroke 260.35
Return Type Spring-Return
Retracted Height 428.75 mm
Cylinder Movement Single-Acting
Extended Height 689.1 mm
Weight 51.26 kgs

Document Image

Item part number

sort

Description

Document Type

sort

Model

Language

Repair Part Number

Document download result

cyl-100-ton-10-1-4-stroke-c10010c-102397

C10010C

CYL, 100 TON 10-1/4" STROKE

Operating Instructions

EN

Preview Asset Download Asset
cyl_100ton10_1_4_stroke_c10010c_a_cylinders_powerteam_102397

C10010C

CYL, 100 TON 10-1/4" STROKE

Operating Instructions

A

EN

Preview Asset Download Asset
cyl_100ton10_1_4_stroke_c10010c_b_cylinders_powerteam_102397

C10010C

CYL, 100 TON 10-1/4" STROKE

Operating Instructions

B

EN

Preview Asset Download Asset
cyl-100-ton-10-1-4-stroke-c10010c-100385

C10010C

CYL, 100 TON 10-1/4" STROKE

Part Sheets

A

EN

Preview Asset Download Asset
cyl_100ton10_1_4_stroke_c10010c_b_cylinders_powerteam_101436

C10010C

CYL, 100 TON 10-1/4" STROKE

Part Sheets

B

EN

Preview Asset Download Asset

Comparable Models

Units:
Product Brand Tonnage Stroke Return Type Retracted Height Cylinder Movement Extended Height Weight
C55C Power Team 5 5.25 Spring-Return 8.5 in Single-Acting 13.75 4
C2514C Power Team 25 14.25 Spring-Return 18.75 in Single-Acting 33 36.8
C51C Power Team 5 1 Spring-Return 4.34 in Single-Acting 5.44 2.25
C5510C Power Team 55 10.25 Spring-Return 15.13 in Single-Acting 25.38 67
C106C Power Team 10 6.13 Spring-Return 9.75 in Single-Acting 15.88 9.4
C151C Power Team 15 1 Spring-Return 4.88 in Single-Acting 5.88 7.5
C1012C Power Team 10 12.13 Spring-Return 15.75 in Single-Acting 27.88 14.6
C2514CBT Power Team 25 14.25 Spring-Return 21.38 in Single-Acting 35.63 40.2
C152C Power Team 15 2.13 Spring-Return 5.88 in Single-Acting 8 8.9
C1016C Power Team 10 16 Spring-Return 20.5 in Single-Acting 36.5 18.5
C104C Power Team 10 4.13 Spring-Return 6.75 in Single-Acting 10.88 6.7
C156C Power Team 15 6.13 Spring-Return 10.69 in Single-Acting 16.81 15.3
C556C Power Team 55 6.25 Spring-Return 11.13 in Single-Acting 17.38 51
C5513C Power Team 55 13.25 Spring-Return 18.13 in Single-Acting 31.38 78
C258C Power Team 25 8.25 Spring-Return 12.75 in Single-Acting 21 25.6
C57C Power Team 5 7.25 Spring-Return 10.75 in Single-Acting 18 5
C2510C Power Team 25 10.25 Spring-Return 14.75 in Single-Acting 25 29.3
C154C Power Team 15 4.13 Spring-Return 7.88 in Single-Acting 12 11.5
C7513C Power Team 75 13.13 Spring-Return 19.38 in Single-Acting 32.5 109.5
C1514C Power Team 15 14.13 Spring-Return 18.69 in Single-Acting 32.81 26
C252C Power Team 25 2 Spring-Return 6.5 in Single-Acting 8.5 13.9
C554C Power Team 55 4.25 Spring-Return 9.13 in Single-Acting 13.38 41.3
C256C Power Team 25 6.25 Spring-Return 10.75 in Single-Acting 17 21.7
C158C Power Team 15 8.13 Spring-Return 12.69 in Single-Acting 20.81 17.9
C2512C Power Team 25 12.25 Spring-Return 16.75 in Single-Acting 29 33.1
C1002C Power Team 100 2 Spring-Return 8.63 in Single-Acting 10.63 63
C101C Power Team 10 1 Spring-Return 3.63 in Single-Acting 4.63 4
C108C Power Team 10 8.13 Spring-Return 11.75 in Single-Acting 19.88 11
C59C Power Team 5 9.25 Spring-Return 12.75 in Single-Acting 22 5.8
C1510C Power Team 15 10.13 Spring-Return 14.69 in Single-Acting 24.81 20.7
C102C Power Team 10 2.13 Spring-Return 4.75 in Single-Acting 6.88 5
C1010C Power Team 10 10.13 Spring-Return 13.75 in Single-Acting 23.88 13
C10010C Power Team 100 10.25 Spring-Return 16.88 in Single-Acting 27.13 113
C1014C Power Team 10 14.3 Spring-Return 17.75 in Single-Acting 31.88 16.2
C55CBT Power Team 5 5.25 Spring-Return 10.5 in Single-Acting 15.75 4.4
C256CBT Power Team 25 6.25 Spring-Return 13.38 in Single-Acting 19.63 24.6
C254C Power Team 25 4 Spring-Return 8.5 in Single-Acting 12.5 17.6
C1006C Power Team 100 6.63 Spring-Return 13.25 in Single-Acting 19.88 91
C1516C Power Team 15 16 Spring-Return 20.56 in Single-Acting 36.56 28.2
C1010CBT Power Team 10 10.13 Spring-Return 15.5 in Single-Acting 25.63 13.9
C552C Power Team 55 2 Spring-Return 6.88 in Single-Acting 8.88 32.5
C308C Power Team 30 8.25 Spring-Return 12.8 in Single-Acting 21.05 36.5
C756C Power Team 75 6.13 Spring-Return 12.38 in Single-Acting 18.5 73.5
C251C Power Team 25 1 Spring-Return 5.5 in Single-Acting 6.5 11.9
C106CBT Power Team 10 6.13 Spring-Return 11.5 in Single-Acting 17.63 10.3
C53C Power Team 5 3.25 Spring-Return 6.5 in Single-Acting 9.75 3.26
C1512C Power Team 15 12.13 Spring-Return 16.69 in Single-Acting 28.81 23.2
WeightCompliance
Product Brand Tonnage Stroke Return Type Retracted Height Cylinder Movement Extended Height Weight
C55C Power Team 4.53 133.35 Spring-Return 8.5 in Single-Acting 349.25 1.81
C2514C Power Team 22.68 361.95 Spring-Return 18.75 in Single-Acting 838.2 16.69
C51C Power Team 4.53 25.4 Spring-Return 4.34 in Single-Acting 138.18 1.02
C5510C Power Team 49.9 260.35 Spring-Return 15.13 in Single-Acting 644.65 30.39
C106C Power Team 9.07 155.7 Spring-Return 9.75 in Single-Acting 403.35 4.26
C151C Power Team 13.6 25.4 Spring-Return 4.88 in Single-Acting 149.35 3.4
C1012C Power Team 9.07 308.1 Spring-Return 15.75 in Single-Acting 708.15 6.62
C2514CBT Power Team 22.68 361.95 Spring-Return 21.38 in Single-Acting 905 18.23
C152C Power Team 13.6 54.1 Spring-Return 5.88 in Single-Acting 203.2 4.04
C1016C Power Team 9.07 406.4 Spring-Return 20.5 in Single-Acting 927.1 8.39
C104C Power Team 9.07 104.9 Spring-Return 6.75 in Single-Acting 276.35 3.04
C156C Power Team 13.6 155.7 Spring-Return 10.69 in Single-Acting 426.97 6.94
C556C Power Team 49.9 158.75 Spring-Return 11.13 in Single-Acting 441.45 23.13
C5513C Power Team 49.9 336.55 Spring-Return 18.13 in Single-Acting 797.05 35.38
C258C Power Team 22.68 209.55 Spring-Return 12.75 in Single-Acting 533.4 11.61
C57C Power Team 4.53 184.15 Spring-Return 10.75 in Single-Acting 457.2 2.27
C2510C Power Team 22.68 260.35 Spring-Return 14.75 in Single-Acting 635 13.29
C154C Power Team 13.6 104.9 Spring-Return 7.88 in Single-Acting 304.8 5.22
C7513C Power Team 68.03 333.5 Spring-Return 19.38 in Single-Acting 825.5 49.67
C1514C Power Team 13.6 358.9 Spring-Return 18.69 in Single-Acting 833.37 11.79
C252C Power Team 22.68 50.8 Spring-Return 6.5 in Single-Acting 215.9 6.3
C554C Power Team 49.9 107.95 Spring-Return 9.13 in Single-Acting 339.85 18.73
C256C Power Team 22.68 158.75 Spring-Return 10.75 in Single-Acting 431.8 9.84
C158C Power Team 13.6 206.5 Spring-Return 12.69 in Single-Acting 528.57 8.12
C2512C Power Team 22.68 311.15 Spring-Return 16.75 in Single-Acting 736.6 15.01
C1002C Power Team 90.72 50.8 Spring-Return 8.63 in Single-Acting 270 28.58
C101C Power Team 9.07 25.4 Spring-Return 3.63 in Single-Acting 117.6 1.81
C108C Power Team 9.07 206.5 Spring-Return 11.75 in Single-Acting 504.95 4.99
C59C Power Team 4.53 234.95 Spring-Return 12.75 in Single-Acting 558.8 2.63
C1510C Power Team 13.6 257.3 Spring-Return 14.69 in Single-Acting 630.17 9.39
C102C Power Team 9.07 54.1 Spring-Return 4.75 in Single-Acting 174.75 2.27
C1010C Power Team 9.07 257.3 Spring-Return 13.75 in Single-Acting 606.55 5.9
C10010C Power Team 90.72 260.35 Spring-Return 16.88 in Single-Acting 689.1 51.26
C1014C Power Team 9.07 363.22 Spring-Return 17.75 in Single-Acting 809.75 7.35
C55CBT Power Team 4.53 133.35 Spring-Return 10.5 in Single-Acting 400.05 2
C256CBT Power Team 22.68 158.75 Spring-Return 13.38 in Single-Acting 498.6 11.16
C254C Power Team 22.68 101.6 Spring-Return 8.5 in Single-Acting 317.5 7.98
C1006C Power Team 90.72 168.4 Spring-Return 13.25 in Single-Acting 504.95 41.28
C1516C Power Team 13.6 406.4 Spring-Return 20.56 in Single-Acting 928.62 12.79
C1010CBT Power Team 9.07 257.3 Spring-Return 15.5 in Single-Acting 651 6.3
C552C Power Team 49.9 50.8 Spring-Return 6.88 in Single-Acting 225.55 14.74
C308C Power Team 27.21 209.55 Spring-Return 12.8 in Single-Acting 534.67 16.56
C756C Power Team 68.03 155.7 Spring-Return 12.38 in Single-Acting 469.9 33.34
C251C Power Team 22.68 25.4 Spring-Return 5.5 in Single-Acting 165.1 5.4
C106CBT Power Team 9.07 155.7 Spring-Return 11.5 in Single-Acting 447.8 4.67
C53C Power Team 4.53 82.55 Spring-Return 6.5 in Single-Acting 247.65 1.48
C1512C Power Team 13.6 308.1 Spring-Return 16.69 in Single-Acting 731.77 10.52
