CYLINDER 10IN 200T SINGLE ACTING, LOAD RETURN, LOCKING COLLAR W/ SWIVEL CAP, NITRIDE

Features:

  • Positive mechanical locking collar safely supports load for extended periods of time with hydraulic pressure released.
  • Patented swivel cap provides concentrated load centering up to 5 degrees.
  • Sealing technology provides rod lubrication to reduce friction and wear.
  • Robust retaining ring withstands full load end stop and conforms with ANSI B30.1 standards. Power-tech nitro-carburization surface treatment inhibits corrosion and provides exceptional durability.
  • Power-tech nitro-carburization surface treatment inhibits corrosion and provides exceptional durability.
Where to buy
Add to quote
  • Overview
  • Specifications
  • Documentation
HEAVY LIFT, GENERAL PURPOSE CYLINDER FOR TOUGH MAINTENANCE APPLICATIONS.
Units:
  • Imperial
  • Metric
Specification
Imperial
Brand Power Team
Tonnage 200
Stroke 10
Return Type Load-Return
Retracted Height 18.59 in
Cylinder Movement Single-Acting
Extended Height 28.59 in
Weight 259.3
Cylinder Eff. Area 41.28
Specification 12
Metric
Brand Power Team
Tonnage 181.43
Stroke 254
Return Type Load-Return
Retracted Height 472.19 mm
Cylinder Movement Single-Acting
Extended Height 726.19 mm
Weight 117.62 kgs
Cylinder Eff. Area 266.34

Comparable Models

Units:
Product Brand Tonnage Stroke Return Type Retracted Height Cylinder Movement Extended Height Weight Cylinder Eff. Area
RGL2506 Power Team 250 6 Load-Return 15.74 in Single-Acting 21.74 302.3 50.26
RGL6004 Power Team 600 4 Load-Return 19.01 in Single-Acting 23.01 938.2 122.71
RGL2508 Power Team 250 8 Load-Return 17.74 in Single-Acting 25.74 334.7 50.26
RGL60012 Power Team 600 12 Load-Return 27.01 in Single-Acting 39.01 1257.1 122.71
RGL754 Power Team 75 4 Load-Return 10.22 in Single-Acting 14.22 61.7 15.03
RGL2006 Power Team 200 6 Load-Return 14.59 in Single-Acting 20.59 210.3 41.28
RGL1002 Power Team 100 2 Load-Return 8.69 in Single-Acting 10.69 68.2 20.63
RGL40010 Power Team 400 10 Load-Return 23.62 in Single-Acting 33.62 775.7 86.6
RGL2502 Power Team 250 2 Load-Return 11.74 in Single-Acting 13.74 237.4 50.26
RGL3002 Power Team 300 2 Load-Return 13.74 in Single-Acting 15.74 356.8 63.62
RGL5006 Power Team 500 6 Load-Return 20.3 in Single-Acting 26.3 846.6 103.87
RGL5004 Power Team 500 4 Load-Return 18.3 in Single-Acting 22.3 780.8 103.87
RGL6008 Power Team 600 8 Load-Return 23.01 in Single-Acting 31.01 1097.7 122.71
RGL752 Power Team 75 2 Load-Return 8.22 in Single-Acting 10.22 51.3 15.03
RGL25012 Power Team 250 12 Load-Return 21.74 in Single-Acting 33.74 399.6 50.26
RGL2002 Power Team 200 2 Load-Return 10.59 in Single-Acting 12.59 161.3 41.28
RGL2008 Power Team 200 8 Load-Return 16.59 in Single-Acting 24.59 234.8 41.28
RGL7510 Power Team 75 10 Load-Return 16.22 in Single-Acting 26.22 93.2 15.03
RGL1504 Power Team 150 4 Load-Return 11.6 in Single-Acting 15.6 125.5 30.68
RGL2504 Power Team 250 4 Load-Return 13.74 in Single-Acting 17.74 269.8 50.26
RGL5002 Power Team 500 2 Load-Return 16.3 in Single-Acting 18.3 714.9 103.87
RGL5510 Power Team 55 10 Load-Return 15.78 in Single-Acting 25.78 73.8 11.04
RGL50010 Power Team 500 10 Load-Return 24.3 in Single-Acting 34.3 978.2 103.87
RGL5008 Power Team 500 8 Load-Return 22.3 in Single-Acting 30.3 912.4 103.87
RGL3008 Power Team 300 8 Load-Return 19.74 in Single-Acting 27.74 477.1 63.62
RGL30010 Power Team 300 10 Load-Return 21.74 in Single-Acting 31.74 517.1 63.62
RGL554 Power Team 55 4 Load-Return 9.78 in Single-Acting 13.78 47.6 11.04
RGL1004 Power Team 100 4 Load-Return 10.69 in Single-Acting 14.69 81.5 20.63
RGL60010 Power Team 600 10 Load-Return 25.01 in Single-Acting 35.01 1177.4 122.71
RGL50012 Power Team 500 12 Load-Return 26.3 in Single-Acting 38.3 1044 103.87
RGL4002 Power Team 400 2 Load-Return 15.62 in Single-Acting 17.62 559.4 86.6
RGL1006 Power Team 100 6 Load-Return 12.69 in Single-Acting 18.69 94.7 20.63
RGL40012 Power Team 400 12 Load-Return 25.62 in Single-Acting 37.62 829.8 86.6
RGL756 Power Team 75 6 Load-Return 12.22 in Single-Acting 18.22 72.2 15.03
RGL1502 Power Team 150 2 Load-Return 9.6 in Single-Acting 11.6 107.5 30.68
RGL25010 Power Team 250 10 Load-Return 19.74 in Single-Acting 29.74 367.2 50.26
RGL5512 Power Team 55 12 Load-Return 17.78 in Single-Acting 29.78 82.5 11.04
RGL30012 Power Team 300 12 Load-Return 23.74 in Single-Acting 35.74 557.2 63.62
RGL4006 Power Team 400 6 Load-Return 19.62 in Single-Acting 25.62 667.5 86.6
RGL4008 Power Team 400 8 Load-Return 21.62 in Single-Acting 29.62 721.6 86.6
RGL20012 Power Team 200 12 Load-Return 20.59 in Single-Acting 32.59 283.8 41.28
RGL3006 Power Team 300 6 Load-Return 17.74 in Single-Acting 23.74 437 63.62
RGL7512 Power Team 75 12 Load-Return 18.22 in Single-Acting 30.22 103.6 15.03
RGL758 Power Team 75 8 Load-Return 14.22 in Single-Acting 22.22 82.7 15.03
RGL4004 Power Team 400 4 Load-Return 17.62 in Single-Acting 21.62 613.4 86.6
RGL10012 Power Team 100 12 Load-Return 18.69 in Single-Acting 30.69 134.3 20.63
RGL1508 Power Team 150 8 Load-Return 15.6 in Single-Acting 23.6 161.4 30.68
RGL552 Power Team 55 2 Load-Return 7.78 in Single-Acting 9.78 38.8 11.04
RGL15012 Power Team 150 12 Load-Return 19.6 in Single-Acting 31.6 197.4 30.68
RGL6002 Power Team 600 2 Load-Return 17.01 in Single-Acting 19.01 858.5 122.71
RGL558 Power Team 55 8 Load-Return 13.78 in Single-Acting 21.78 65.1 11.04
RGL1506 Power Team 150 6 Load-Return 13.6 in Single-Acting 19.6 143.4 30.68
RGL20010 Power Team 200 10 Load-Return 18.59 in Single-Acting 28.59 259.3 41.28
RGL1008 Power Team 100 8 Load-Return 14.69 in Single-Acting 22.69 107.9 20.63
RGL10010 Power Team 100 10 Load-Return 16.69 in Single-Acting 26.69 121.1 20.63
RGL2004 Power Team 200 4 Load-Return 12.59 in Single-Acting 16.59 185.8 41.28
RGL15010 Power Team 150 10 Load-Return 17.6 in Single-Acting 27.6 179.4 30.68
RGL6006 Power Team 600 6 Load-Return 21.01 in Single-Acting 27.01 1017.9 122.71
RGL556 Power Team 55 6 Load-Return 11.78 in Single-Acting 17.78 56.3 11.04
RGL3004 Power Team 300 4 Load-Return 15.74 in Single-Acting 19.74 396.9 63.62
WeightCompliance
Product Brand Tonnage Stroke Return Type Retracted Height Cylinder Movement Extended Height Weight Cylinder Eff. Area
RGL2506 Power Team 226.79 152.4 Load-Return 399.8 mm Single-Acting 552.2 137.12 324.28
RGL6004 Power Team 544.31 101.6 Load-Return 482.85 mm Single-Acting 584.45 425.56 791.72
RGL2508 Power Team 226.79 203.2 Load-Return 450.6 mm Single-Acting 653.8 151.82 324.28
RGL60012 Power Team 544.31 304.8 Load-Return 686.05 mm Single-Acting 990.85 570.21 791.72
RGL754 Power Team 68.03 101.6 Load-Return 259.59 mm Single-Acting 361.19 27.99 96.97
RGL2006 Power Team 181.43 152.4 Load-Return 370.59 mm Single-Acting 522.99 95.39 266.34
RGL1002 Power Team 90.72 50.8 Load-Return 220.73 mm Single-Acting 271.53 30.93 133.1
RGL40010 Power Team 362.87 254 Load-Return 599.95 mm Single-Acting 853.95 351.85 558.74
RGL2502 Power Team 226.79 50.8 Load-Return 298.2 mm Single-Acting 349 107.68 324.28
RGL3002 Power Team 272.15 50.8 Load-Return 349 mm Single-Acting 399.8 161.84 410.48
RGL5006 Power Team 453.59 152.4 Load-Return 515.62 mm Single-Acting 668.02 384.01 670.17
RGL5004 Power Team 453.59 101.6 Load-Return 464.82 mm Single-Acting 566.42 354.16 670.17
RGL6008 Power Team 544.31 203.2 Load-Return 584.45 mm Single-Acting 787.65 497.91 791.72
RGL752 Power Team 68.03 50.8 Load-Return 208.79 mm Single-Acting 259.59 23.27 96.97
RGL25012 Power Team 226.79 304.8 Load-Return 552.2 mm Single-Acting 857 181.26 324.28
RGL2002 Power Team 181.43 50.8 Load-Return 268.99 mm Single-Acting 319.79 73.16 266.34
RGL2008 Power Team 181.43 203.2 Load-Return 421.39 mm Single-Acting 624.59 106.5 266.34
RGL7510 Power Team 68.03 254 Load-Return 411.99 mm Single-Acting 665.99 42.27 96.97
RGL1504 Power Team 136.07 101.6 Load-Return 294.64 mm Single-Acting 396.24 56.93 197.95
RGL2504 Power Team 226.79 101.6 Load-Return 349 mm Single-Acting 450.6 122.38 324.28
RGL5002 Power Team 453.59 50.8 Load-Return 414.02 mm Single-Acting 464.82 324.27 670.17
RGL5510 Power Team 49.9 254 Load-Return 400.81 mm Single-Acting 654.81 33.48 71.23
RGL50010 Power Team 453.59 254 Load-Return 617.22 mm Single-Acting 871.22 443.7 670.17
RGL5008 Power Team 453.59 203.2 Load-Return 566.42 mm Single-Acting 769.62 413.86 670.17
RGL3008 Power Team 272.15 203.2 Load-Return 501.4 mm Single-Acting 704.6 216.41 410.48
RGL30010 Power Team 272.15 254 Load-Return 552.2 mm Single-Acting 806.2 234.55 410.48
RGL554 Power Team 49.9 101.6 Load-Return 248.41 mm Single-Acting 350.01 21.59 71.23
RGL1004 Power Team 90.72 101.6 Load-Return 271.53 mm Single-Acting 373.13 36.97 133.1
RGL60010 Power Team 544.31 254 Load-Return 635.25 mm Single-Acting 889.25 534.06 791.72
RGL50012 Power Team 453.59 304.8 Load-Return 668.02 mm Single-Acting 972.82 473.55 670.17
RGL4002 Power Team 362.87 50.8 Load-Return 396.75 mm Single-Acting 447.55 253.74 558.74
RGL1006 Power Team 90.72 152.4 Load-Return 322.33 mm Single-Acting 474.73 42.96 133.1
RGL40012 Power Team 362.87 304.8 Load-Return 650.75 mm Single-Acting 955.55 376.39 558.74
RGL756 Power Team 68.03 152.4 Load-Return 310.39 mm Single-Acting 462.79 32.75 96.97
RGL1502 Power Team 136.07 50.8 Load-Return 243.84 mm Single-Acting 294.64 48.76 197.95
RGL25010 Power Team 226.79 254 Load-Return 501.4 mm Single-Acting 755.4 166.56 324.28
RGL5512 Power Team 49.9 304.8 Load-Return 451.61 mm Single-Acting 756.41 37.42 71.23
RGL30012 Power Team 272.15 304.8 Load-Return 603 mm Single-Acting 907.8 252.74 410.48
RGL4006 Power Team 362.87 152.4 Load-Return 498.35 mm Single-Acting 650.75 302.77 558.74
RGL4008 Power Team 362.87 203.2 Load-Return 549.15 mm Single-Acting 752.35 327.31 558.74
RGL20012 Power Team 181.43 304.8 Load-Return 522.99 mm Single-Acting 827.79 128.73 266.34
RGL3006 Power Team 272.15 152.4 Load-Return 450.6 mm Single-Acting 603 198.22 410.48
RGL7512 Power Team 68.03 304.8 Load-Return 462.79 mm Single-Acting 767.59 46.99 96.97
RGL758 Power Team 68.03 203.2 Load-Return 361.19 mm Single-Acting 564.39 37.51 96.97
RGL4004 Power Team 362.87 101.6 Load-Return 447.55 mm Single-Acting 549.15 278.23 558.74
RGL10012 Power Team 90.72 304.8 Load-Return 474.73 mm Single-Acting 779.53 60.92 133.1
RGL1508 Power Team 136.07 203.2 Load-Return 396.24 mm Single-Acting 599.44 73.21 197.95
RGL552 Power Team 49.9 50.8 Load-Return 197.61 mm Single-Acting 248.41 17.6 71.23
RGL15012 Power Team 136.07 304.8 Load-Return 497.84 mm Single-Acting 802.64 89.54 197.95
RGL6002 Power Team 544.31 50.8 Load-Return 432.05 mm Single-Acting 482.85 389.41 791.72
RGL558 Power Team 49.9 203.2 Load-Return 350.01 mm Single-Acting 553.21 29.53 71.23
RGL1506 Power Team 136.07 152.4 Load-Return 345.44 mm Single-Acting 497.84 65.05 197.95
RGL20010 Power Team 181.43 254 Load-Return 472.19 mm Single-Acting 726.19 117.62 266.34
RGL1008 Power Team 90.72 203.2 Load-Return 373.13 mm Single-Acting 576.33 48.94 133.1
RGL10010 Power Team 90.72 254 Load-Return 423.93 mm Single-Acting 677.93 54.93 133.1
RGL2004 Power Team 181.43 101.6 Load-Return 319.79 mm Single-Acting 421.39 84.28 266.34
RGL15010 Power Team 136.07 254 Load-Return 447.04 mm Single-Acting 701.04 81.37 197.95
RGL6006 Power Team 544.31 152.4 Load-Return 533.65 mm Single-Acting 686.05 461.71 791.72
RGL556 Power Team 49.9 152.4 Load-Return 299.21 mm Single-Acting 451.61 25.54 71.23
RGL3004 Power Team 272.15 101.6 Load-Return 399.8 mm Single-Acting 501.4 180.03 410.48
