In regions where infrastructure development faces steep logistical challenges, reliable hydraulic solutions can make the difference between success and delay. This case study explores how Power Team hydraulic technologies, using a gas-powered hydraulic pump and RD-series hydraulic cylinders, enabled the launch of a steel bridge in a developing country without access to cranes or traditional heavy machinery.
The Challenge: Infrastructure in Remote Locations
An international contractor was pioneering a bridge construction method designed specifically for third-world countries. Their goal was to create a scalable bridge-launching system that:
- Required no cranes or large transport equipment
- Operated reliably in off-grid environments
- Could be installed and maintained by a scale of teams
This ambitious infrastructure project demanded a compact, mobile hydraulic system capable of high-force performance without reliance on electrical power.
The Power Team Hydraulic System in Action
Key Components Used
To meet the project’s requirements, Power Team engineers designed a customized hydraulic setup featuring:
- (6) RD10013 Hydraulic Cylinders – Strategically positioned to distribute force and provide lift
- (1) PG554 Gas-Powered Hydraulic Pump – Perfect for locations with no electrical infrastructure
- (1) 9575 Valve – Ensuring safe, precise control under load
- (1) 9691 Y-Manifold – Streamlining hydraulic fluid distribution
- Complete fittings & gauge package – For turnkey setup and real-time pressure monitoring
Four cylinders were mounted near the gap to control descent, while two rear-mounted cylinders provided the forward launching force.
This hydraulic system became the backbone of a successful bridge-launching method in an area previously thought too remote for modern construction.
Why Power Team Hydraulic Technologies Were the Ideal Fit
Precision Where It Counts
Precision Where It Counts
Bridge alignment requires millimeter-level accuracy. The system’s control valve and RD-series cylinders allowed for finely tuned, stable movement even under fluctuating load conditions.
Portability and Power
With no electrical grid available, the PG554 hydraulic pump offered dependable, off-grid performance. The pump’s compact gas-powered design provided exceptional power-to-weight performance ideal for the terrain.
Sustained Load Endurance
Bridge launching requires continuous pressure over time. Power Team products are engineered for durability across long duty cycles in demanding environments.
Scalable for Future Projects
The solution is now repeatable across other remote sites and is easy to scale for larger spans or varying load requirements.
Results
The bridge launched successfully using only hydraulic power, while also:
- Significantly reduced logistics costs and setup time.
- Enabled rapid deployment of essential infrastructure in a low-resource setting.
- Created a replicable model for similar projects across developing regions.
The Power Team Advantage
This project exemplifies how Hydraulic Technologies can enable critical infrastructure development in areas where other systems fall short.
Featured Products in This Case Study:
- RD10013 Hydraulic Cylinder
- PG554 Hydraulic Pump (Gas Powered)
- 9575 Precision Valve
- 9691 Y-Manifold
Let’s Solve Your Infrastructure Challenges
If you're planning infrastructure development in urban, off-grid, or resource-constrained areas, Power Team hydraulic technologies offer unmatched performance and reliability.
Count on Power Team to deliver hydraulic tools built for the world's toughest jobs, and rely on our team to help you plan the logistics to make big moves possible.
