PUMP,E 30 CU IN/MIN, 110/115VAC, 50/60HZ

Features:

  • Deliver a powerful punch to operate single-acting or double-acting cylinders.
  • Integral roll cage protects pump from abuse.
  • 1 HP, single-phase, permanent magnet motor.
  • High-performance-to-weight ratio.
  • Starts under full load even when voltage is reduced to 50% of nominal rating.
  • Quiet operation: 82 dBA @ 10,000 psi and 87 dBA @ 0 psi.
  • Remote controls and/or solenoid valves feature 24VAC controls.
  • CSA rated for intermittent duty.
Where to buy
Add to quote
  • Overview
  • Specifications
  • Documentation
FOR MAINTENANCE AND CONSTRUCTION APPLICATIONS.
Units:
  • Imperial
  • Metric
Specification
Imperial
Brand Power Team
Max Flow 30 in3/min
Pump Voltage 115 VAC
Reservoir Capacity 1.64 gal
Oper. Pressure 10000 psi
Cylinder Compatibility Single-Acting
Valve Operation Manually Operated
Valve Type 3W2P
Weight 64 Ibs
Compliance
Specification 12
Metric
Brand Power Team
Max Flow 0.49 L/min
Pump Voltage 115 VAC
Reservoir Capacity 6.21 L
Oper. Pressure 689 bar
Cylinder Compatibility Single-Acting
Valve Operation Manually Operated
Valve Type 3W2P
Weight 29.1 kgs
Compliance

Document Image

Item part number

sort

Description

Document Type

sort

Model

Language

Repair Part Number

Document download result

pump-elec-110-115v-50-60hz-pe302r-2-102838

PE302R-2

PUMP, ELEC 110/115V 50/60HZ

Operating Instructions

EN

Preview Asset Download Asset
pump_elec110_115v50_60hz_pe302r_2_a_pumps_powerteam_102838

PE302R-2

PUMP, ELEC 110/115V 50/60HZ

Operating Instructions

A

EN

Preview Asset Download Asset
pump_elec110_115v50_60hz_pe302r_2_b_pumps_powerteam_102838

PE302R-2

PUMP, ELEC 110/115V 50/60HZ

Operating Instructions

B

EN

Preview Asset Download Asset
pump-elec-110-115v-50-60hz-pe302r-2-101450

PE302R-2

PUMP, ELEC 110/115V 50/60HZ

Part Sheets

EN

Preview Asset Download Asset
pump_elec110_115v50_60hz_pe302r_2_a_pumps_powerteam_101450

PE302R-2

PUMP, ELEC 110/115V 50/60HZ

Part Sheets

A

EN

Preview Asset Download Asset

Comparable Models

Units:
Product Brand Flow Voltage Reservoir Capacity (in3) Oper. Pressure Cylinder Compatibility Valve Operation Valve Type: Weight Compliance
PE304-220 Power Team 30In3 230 VAC 1.64 in3/min 10000 Psi Double-acting Manually Operated 4W3P Tandem Center 50.1 -
PE303 Power Team 30In3 115 VAC 1.21 in3/min 10000 Psi Single-Acting Manually Operated 3W3P Tandem Center 50.1 -
PE304R Power Team 30In3 115 VAC 1.21 in3/min 10000 Psi Double-acting Manually Operated 4W3P Tandem Center 50.1 -
PE302-220 Power Team 30In3 230 VAC 1.64 in3/min 10000 Psi Single-Acting Manually Operated 3W2P 50.1 -
PE302-50-220 Power Team 30In3 230 VAC 1.64 in3/min 10000 Psi Single-Acting Manually Operated 3W2P 50.1 -
PE303R-2 Power Team 30In3 115 VAC 1.64 in3/min 10000 Psi Single-Acting Manually Operated 3W3P Tandem Center 64 -
PE303-220 Power Team 30In3 230 VAC 1.64 in3/min 10000 Psi Single-Acting Manually Operated 3W3P Tandem Center 50.1 -
PE302-2-220 Power Team 30In3 230 VAC 1.64 in3/min 10000 Psi Single-Acting Manually Operated 3W2P 64 -
PE302R-220 Power Team 30In3 230 VAC 1.64 in3/min 10000 Psi Single-Acting Manually Operated 3W2P 50.1 -
PE302S-2 Power Team 30In3 115 VAC 1.61 in3/min 10000 Psi Single-Acting Solenoid Operated 3W2P 64 -
PE302R Power Team 30In3 115 VAC 1.21 in3/min 10000 Psi Single-Acting Manually Operated 3W2P 50.1 -
PE303R-220 Power Team 30In3 230 VAC 1.64 in3/min 10000 Psi Single-Acting Manually Operated 3W3P Tandem Center 50.1 -
PE303R-2-220 Power Team 30In3 230 VAC 1.64 in3/min 10000 Psi Single-Acting Manually Operated 3W3P Tandem Center 64 -
PE302R-2 Power Team 30In3 115 VAC 1.64 in3/min 10000 Psi Single-Acting Manually Operated 3W2P 64 -
PE303R Power Team 30In3 115 VAC 1.21 in3/min 10000 Psi Single-Acting Manually Operated 3W3P Tandem Center 50.1 -
PE304-2 Power Team 30In3 115 VAC 1.64 in3/min 10000 Psi Double-acting Manually Operated 4W3P Tandem Center 64 -
PE302A Power Team 30In3 115 VAC 1.21 in3/min 10000 Psi Single-Acting Manually Operated 3W2P 50.1 -
PE302S-220 Power Team 30In3 230 VAC 1.64 in3/min 10000 Psi Single-Acting Solenoid Operated 3W2P 50.1 -
PE302 Power Team 30In3 115 VAC 1.21 in3/min 10000 Psi Single-Acting Manually Operated 3W2P 50.1 -
PE302-2 Power Team 30In3 115 VAC 1.64 in3/min 10000 Psi Single-Acting Manually Operated 3W2P 64 -
PE304R-220 Power Team 30In3 230 VAC 1.64 in3/min 10000 Psi Double-acting Manually Operated 4W3P Tandem Center 50.1 -
PE304 Power Team 30In3 115 VAC 1.21 in3/min 10000 Psi Double-acting Manually Operated 4W3P Tandem Center 50.1 -
PE302S Power Team 30In3 115 VAC 1.21 in3/min 10000 Psi Single-Acting Manually Operated 3W2P 50.1 -
PE302A-2 Power Team 30In3 115 VAC 1.64 in3/min 10000 Psi Single-Acting Manually Operated 3W2P 64 -
PE304R-2 Power Team 30In3 115 VAC 1.64 in3/min 10000 Psi Double-acting Manually Operated 4W3P Tandem Center 64 -
PE303-2 Power Team 30In3 115 VAC 1.64 in3/min 10000 Psi Single-Acting Manually Operated 3W3P Tandem Center 64 -
WeightCompliance
Product Brand Flow Voltage Reservoir Capacity (in3) Oper. Pressure Cylinder Compatibility Valve Operation Valve Type: Weight Compliance
PE304-220 Power Team 0.49l 230 VAC 6.21l 689bar Double-Acting Manually Operated 4W3P Tandem Center 22.8 -
PE303 Power Team 0.49l 115 VAC 4.58l 689bar Single-Acting Manually Operated 3W3P Tandem Center 22.8 -
PE304R Power Team 0.49l 115 VAC 4.58l 689bar Double-Acting Manually Operated 4W3P Tandem Center 22.8 -
PE302-220 Power Team 0.49l 230 VAC 6.21l 689bar Single-Acting Manually Operated 3W2P 22.8 -
PE302-50-220 Power Team 0.49l 230 VAC 6.21l 689bar Single-Acting Manually Operated 3W2P 22.8 -
PE303R-2 Power Team 0.49l 115 VAC 6.21l 689bar Single-Acting Manually Operated 3W3P Tandem Center 29.1 -
PE303-220 Power Team 0.49l 230 VAC 6.21l 689bar Single-Acting Manually Operated 3W3P Tandem Center 22.8 -
PE302-2-220 Power Team 0.49l 230 VAC 6.21l 689bar Single-Acting Manually Operated 3W2P 29.1 -
PE302R-220 Power Team 0.49l 230 VAC 6.21l 689bar Single-Acting Manually Operated 3W2P 22.8 -
PE302S-2 Power Team 0.49l 115 VAC 6.09l 689bar Single-Acting Solenoid Operated 3W2P 29.1 -
PE302R Power Team 0.49l 115 VAC 4.58l 689bar Single-Acting Manually Operated 3W2P 22.8 -
PE303R-220 Power Team 0.49l 230 VAC 6.21l 689bar Single-Acting Manually Operated 3W3P Tandem Center 22.8 -
PE303R-2-220 Power Team 0.49l 230 VAC 6.21l 689bar Single-Acting Manually Operated 3W3P Tandem Center 29.1 -
PE302R-2 Power Team 0.49l 115 VAC 6.21l 689bar Single-Acting Manually Operated 3W2P 29.1 -
PE303R Power Team 0.49l 115 VAC 4.58l 689bar Single-Acting Manually Operated 3W3P Tandem Center 22.8 -
PE304-2 Power Team 0.49l 115 VAC 6.21l 689bar Double-Acting Manually Operated 4W3P Tandem Center 29.1 -
PE302A Power Team 0.49l 115 VAC 4.58l 689bar Single-Acting Manually Operated 3W2P 22.8 -
PE302S-220 Power Team 0.49l 230 VAC 6.21l 689bar Single-Acting Solenoid Operated 3W2P 22.8 -
PE302 Power Team 0.49l 115 VAC 4.58l 689bar Single-Acting Manually Operated 3W2P 22.8 -
PE302-2 Power Team 0.49l 115 VAC 6.21l 689bar Single-Acting Manually Operated 3W2P 29.1 -
PE304R-220 Power Team 0.49l 230 VAC 6.21l 689bar Double-Acting Manually Operated 4W3P Tandem Center 22.8 -
PE304 Power Team 0.49l 115 VAC 4.58l 689bar Double-Acting Manually Operated 4W3P Tandem Center 22.8 -
PE302S Power Team 0.49l 115 VAC 4.58l 689bar Single-Acting Manually Operated 3W2P 22.8 -
PE302A-2 Power Team 0.49l 115 VAC 6.21l 689bar Single-Acting Manually Operated 3W2P 29.1 -
PE304R-2 Power Team 0.49l 115 VAC 6.21l 689bar Double-Acting Manually Operated 4W3P Tandem Center 29.1 -
PE303-2 Power Team 0.49l 115 VAC 6.21l 689bar Single-Acting Manually Operated 3W3P Tandem Center 29.1 -
